Frame
Ultralight 500 Series OCLV Carbon, Ride Tuned performance tube optimisation, tapered head tube, internal routing, DuoTrap S-compatible, flat-mount disc, 142x12 mm thru axle
Fork
Émonda SL full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm thru axle
Weight
56 - 7.90 kg / 17.42 lbs
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
Charger
Charging cable included
Shifter
Shimano Ultegra R8170 Di2, 12-speed
Front derailleur
Shimano Ultegra R8150 Di2, braze-on, down swing
Rear derailleur
Shimano Ultegra R8150 Di2, 34T max cog
Crank
Size: 47
Shimano Ultegra R8100, 52/36, 165 mm length
Size: 50, 52
Shimano Ultegra R8100, 52/36, 170 mm length
Size: 54, 56, 58
Shimano Ultegra R8100, 52/36, 172.5 mm length
Size: 60, 62
Shimano Ultegra R8100, 52/36, 175 mm length
Bottom bracket
Praxis, T47 threaded, internal bearing
Cassette
Shimano Ultegra R8100, 11-30, 12 speed
Chain
Shimano XT M8100, 12-speed
Max. chainring size
1x: 50T, 2x: 53/39
Wheel front
Bontrager Aeolus Pro 37, OCLV Carbon, Tubeless Ready, 37 mm rim depth, 100x12 mm thru axle
Wheel rear
Bontrager Aeolus Pro 37, OCLV Carbon, Tubeless-Ready, 37 mm rim depth, Shimano 11-speed freehub, 142x12 mm thru axle
Skewer front
Bontrager Switch thru axle, removable lever
Skewer rear
Bontrager Switch thru-axle, removable lever
Tyre
Bontrager R3 Hard-Case Lite, Tubeless-Ready, carbon bead, 170 tpi, 700x25 mm
Tyre part
Bontrager TLR sealant, 180 ml/6 oz
Rim strip
Bontrager Aeolus XXX rim strip
Max tyre size
28mm
Saddle
Bontrager Aeolus Comp, steel rails, 145 mm width
Seatpost
Size: 47, 50, 52, 54
Bontrager carbon seat mast cap, 20 mm offset, short length
Size: 56, 58, 60, 62
Bontrager carbon seat mast cap, 20 mm offset, tall length
Handlebar
Size: 47, 50
Bontrager Pro VR-C, OCLV Carbon, 31.8 mm, Di2 routing, 100 mm reach, 124 mm drop, 38 cm width
Size: 52
Bontrager Pro VR-C, OCLV Carbon, 31.8 mm, Di2 routing, 100 mm reach, 124 mm drop, 40 cm width
Size: 54, 56, 58
Bontrager Pro VR-C, OCLV Carbon, 31.8 mm, Di2 routing, 100 mm reach, 124 mm drop, 42 cm width
Size: 60, 62
Bontrager Pro VR-C, OCLV Carbon, 31.8 mm, Di2 routing, 100 mm reach, 124 mm drop, 44 cm width
Handlebar/stem (integrated)
Size: 47, 50
Bontrager Aeolus RSL integrated bar/stem, OCLV Carbon, Di2 routing, 100 mm reach, 124 mm drop, 38 cm width, 80 mm stem length
Size: 52
Bontrager Aeolus RSL integrated bar/stem, OCLV Carbon, Di2 routing, 100 mm reach, 124 mm drop, 40 cm width, 90 mm stem length
Size: 54
Bontrager Aeolus RSL integrated bar/stem, OCLV Carbon, Di2 routing, 100 mm reach, 124 mm drop, 42 cm width, 90 mm stem length
Size: 56
Bontrager Aeolus RSL integrated bar/stem, OCLV Carbon, Di2 routing, 100 mm reach, 124 mm drop, 42 cm width, 100 mm stem length
Size: 58
Bontrager Aeolus RSL integrated bar/stem, OCLV Carbon, Di2 routing, 100 mm reach, 124 mm drop, 42 cm width, 110 mm stem length
Size: 60, 62
Bontrager Aeolus RSL integrated bar/stem, OCLV Carbon, Di2 routing, 100 mm reach, 124 mm drop, 44 cm width, 110 mm stem length
Handlebar tape
Bontrager Supertack Perf tape
Stem
Size: 47
Trek RCS Pro, -7-degree, 70 mm length
Size: 50
Trek RCS Pro, -7-degree, 80 mm length
Size: 52, 54
Trek RCS Pro, -7-degree, 90 mm length
Size: 56
Trek RCS Pro, -7-degree, 100 mm length
Size: 58, 60, 62
Trek RCS Pro, -7-degree, 110 mm length
Brake
Shimano Ultegra hydraulic disc
Brake rotor
Shimano CL800, CentreLock, 160 mm
Rotor size
Max brake rotor sizes: 160 mm front and rear
