Model Year
2025
Frame
SCULTURA CF5 V
Material
Carbon
Max Wheel Size
700x30C
Axle Standard
100x12/ 142x12mm
Bottom Bracket
Pressfit 86.5
Frame Size
XXS, XS, S, M, L, XL
Fork
SCULTURA CF5 disc
Material
Carbon
Max Wheel Size
700x30C
Wheelset
Reynolds BL 46 Expert DB, 100x12mm width front hub, 142x12mm width rear hub
Inner Width
21mm
Height
41mm
Centerlock
Yes
Cassette Compatibility
Shimano HG
Material
Carbon
Tubeless Ready
Yes (tubeless tape and valves included)
Front Tyre
Continental Grand Prix 5000S TR, 700x28C, fold, tubeless ready
Rear Tyre
Continental Grand Prix 5000S TR, 700x28C, fold, tubeless ready
Hubs
MERIDA EXPERT SL, including removable lever, 6/4mm allen key
Crank
Shimano Ultegra, 52-36 teeth
Crank Length
165 mm-3XS-XXS, 170 mm-XS, 172.5 mm-S/M/L, 175 mm-XL
Bottom Bracket
Shimano SM-BB72-41B, Pressfit 86.5
Cassette
Shimano Ultegra R8100, 11-30 teeth, 12 speed
Chain
Shimano M6100-12
Shifters
Shimano Ultegra disc Di2
Front Derailleur
Shimano Ultegra Di2
Rear Derailleur
Shimano Ultegra Di2
Brake Lever
Shimano Ultegra
Brakes
Shimano Ultegra, Hydraulic disc
Rotors
Shimano CL800, 160mm
Headset
MERIDA TEAM SL, VP-MRBHB (OP-203 neck)
Stem
MERIDA TEAM ONE-PIECE INTEGRATED, carbon, 90 mm-3XS/XXS/XS, 100 mm-S, 110 mm-M/L, 120 mm-XL
Stem Size
90 mm-3XS/XXS/XS, 100 mm-S, 110 mm-M/L, 120 mm-XL
Handlebar
MERIDA TEAM SL 1P INTEGRATED, carbon, 380mm (XXS-XS-S), 400mm (M-L-XL)
Grip
MERIDA ROAD Expert
Seat Post
MERIDA TEAM SL, 27.2mm diameter, 15mm setback, Carbon, S-Flex
Seat Clamp
MERIDA EXPERT
Saddle
Prologo Scratch M5, V-mount adapter, incl. MERIDA minitool
Bottle Cage
BC156C-D
