Long rides invariably have some smooth tarmac, some junk pavement over backroads, a cutty singletrack connector, and maybe even your own local Strade Bianche sector. So we built a bike that could take on all of them, do it well, and fit fenders in case the ominous clouds turn into a downpour 130km into your day.
AERO CABLE MANAGEMENT
The Cervélo frame, fork, handlebars, and associated components are designed to hide brake and shift control lines (mechanical, electrical, and hydraulic) from the wind for improved aerodynamics, without sacrificing usability or performance.
PERFORMANCE FIT
The Caledonia-5's integrated stem and two bearing cap options allow for stacks ranging between an aggressive 7mm and a relaxed 22mm without the use of spacers. With a wider fit coordinate range (stack) of 580mm to 687mm, the Caledonia can be slammed or more upright. All while looking and being seamlessly fast in the wind.
REMOVABLE FDM
Our bolt-on front derailleur mount is made from high-strength aluminum alloy and attaches to the frame with two countersunk screws. This allows for easy replacement in the event of damage but also enables you to adapt to new standards as they become available or remove the front derailleur mount completely if you choose a 1x system.
FORK - Cervélo All-Carbon, Tapered Caledonia-5 Fork
HEADSET - FSA IS2 1-1/4 x 1-1/2
THRU AXLES - Cervelo Aero Thru-Axles, 12x100/142
WHEELS - Reserve 40/44
TIRES - Corsa N.EXT TLR G2.0 700x28c
CRANKSET - Shimano Ultegra R8100, 52/36T, 12 Speed
BOTTOM BRACKET - FSA, BBright thread together, 24mm spindle
CHAIN - Shimano M8100, 12 speed
FRONT DERAILLEUR - Shimano Ultegra, R8150, 12 speed
REAR DERAILLEUR - Shimano Ultegra, R8150, 12 speed
CASSETTE - Shimano Ultegra 11-34, 12 Speed
SHIFTERS - Shimano Ultegra, R8170, 12 speed
HANDLEBAR - Cervélo HB13 Carbon, 31.8mm clamp
STEM - Cervélo ST32 Alloy
BRAKE CALIPERS - Shimano Ultegra
SADDLE - Prologo Dimension TiRox
SEATPOST - Cervélo SP24 Carbon
BRAKE ROTOR - Shimano MT800 Centerlock
ACCESSORIES - Cervelo Faceplate Front Computer/Accessory Mount, Cervelo Rear Accessory Mount, Removeable Fender Mounts
INTEGRATED ACCESSORY MOUNTS
Integrated mounts enable the use of fenders, lights, and computers without compromising the aerodynamics or structure of your bike. The built-in mount systems provide a simple and clean-looking solution.
