Frame
Alpha Gold Aluminium, tapered head tube, internal derailleur and dropper post routing, rack and kickstand mount, Boost141, 5 mm QR
*Fork
Size: XSRockShox Judy SL, Solo Air spring, TurnKey lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Lite, 80 mm travelSize: SRockShox Judy SL, Solo Air spring, TurnKey lockout, tapered steerer, Boost110, 15 mm Maxle Lite, 100 mm travelSize: M, ML, L, XL, XXLRockShox Judy SL, Solo Air spring, TurnKey lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 100 mm travel
Max compatible fork travel
120mm, XS: 100mm
Hub front
Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle
Hub rear
Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost141, 5 mm QR
*Rim
Size: XS, SBontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valveSize: M, ML, L, XL, XXLBontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valveSize: M, ML, L, XL, XXLBontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve
Spokes
14 g stainless steel, black
*Tyre
Size: XS, SMaxxis Ardent Race, tubeless, EXO casing, folding bead, 60tpi, 27.5x2.35"Size: M, ML, L, XL, XXLMaxxis Ardent Race, tubeless, EXO casing, folding bead, 60tpi, 29x2.35"
Tyre part
Bontrager TLR sealant, 180 ml/6 oz
Rim strip
Bontrager TLR
Max tyre size
Frame: 27.5x2.80" or 29x2.40", Fork: See manufacturer
Shifter
Shimano Deore M6100, 12-speed
Rear derailleur
Shimano XT M8100, long cage
*Crank
Size: XS, S, MShimano MT511, 30T steel ring, 52mm chainline, 170mm lengthSize: ML, L, XL, XXLShimano MT511, 30T steel ring, 52mm chainline, 175mm length
*Bottom bracket
Size: XS, S, M, ML, L, XL, XXLShimano BB-MT501 BSASize: XS, S, M, ML, L, XL, XXLShimano SM-BB52, 73 mm, threaded external bearing
Cassette
Shimano Deore M6100, 10-51, 12-speed
Chain
Shimano Deore M6100, 12-speed
Pedal
VP-536 nylon platform
Max. chainring size
1x: 32T
Saddle
Bontrager Arvada, steel rails, 138 mm width
*Seatpost
Size: XS, SBontrager alloy, 31.6 mm, 12 mm offset, 330 mm lengthSize: MBontrager alloy, 31.6 mm, 12 mm offset, 360 mm lengthSize: ML, L, XL, XXLBontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
*Handlebar
Size: XSBontrager alloy, 31.8 mm, 5 mm rise, 690 mm widthSize: S, MBontrager alloy, 31.8 mm, 5 mm rise, 720 mm widthSize: ML, L, XL, XXLBontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
Grips
Bontrager XR Trail Comp, nylon lock-on
*Stem
Size: XS, SBontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 60 mm lengthSize: M, MLBontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm lengthSize: LBontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm lengthSize: XL, XXLBontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length
Head set
Semi-integrated, loose ball bearing, 1-1/8" top, 1.5" bottom
Brake
Shimano MT200 hydraulic disc
*Brake rotor
Size: XS, S, M, ML, L, XL, XXLShimano RT26, 6-bolt,160 mmSize: XS, S, M, ML, L, XLShimano RT26, 6-bolt, 160 mmSize: L, XL, XXLShimano RT26, 6-bolt,180 mmSize: L, XLShimano RT26, 6-bolt, 180 mm
Brake Set
Shimano MT200 hydraulic disc
Weight
M - 13.05 kg / 28.78 lbs
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
