Frameset
Frame
Alpha Gold Aluminium, internal cable routing, flat-mount disc, rack and mudguard mounts, 135x5 mm QR
Fork
SR Suntour NEX, coil spring, preload, 50 mm travel, 100x5 mm QR
Wheels
Hub front
Shimano 3.0 watt dynamo hub
Hub rear
Shimano TX505, CenterLock
Rim
Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Tyre
Bontrager H2 Comp, reflective strip, wire bead, 30 tpi, 700x40 mm
Max tyre size
700x50mm
Drivetrain
Shifter
Shimano U4000, 9-speed
Rear derailleur
Shimano CUES U4000
Crank
ProWheel Pro alloy, 40T narrow-wide steel ring, 170 mm length
Bottom bracket
Sealed cartridge, 68 mm
Cassette
Shimano LINKGLIDE LG300, 11-46, 9-speed
Chain
Shimano LG500
Pedal
slip-proof pedals with reflectors
Max. chainring size
1x: 42T, 2x: 36/22
Components
Saddle
Selle Royal Loire
Seatpost
Alloy, adjustable suspension, 27.2 mm, 300 mm length
Handlebar
Alloy, 31.8 mm clamp, 25 mm rise, 630 mm width
Grips
Herrmans Clik, ergonomic, lock-on
*Stem
Size: S, M
Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 85 mm length
Size: L, XL
Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 105 mm length
Brake rotor
Shimano RT10, CenterLock, 160 mm
Brake Set
Tektro HD-M275 hydraulic disc
Rotor size
Max brake rotor sizes: 160 mm front and rear
Accessories
*Light
Size: S, M, L, XL
Herrmans H-Trace ECO dynamo LED
Size: S, M, L, XL
Spanninga Brio, 15 Lux, LED headlight
Kickstand
Alloy, rear-mount kickstand
Cargo rack
MIK-compatible alloy rear rack, maximum load 25 kg
*Mudguard
Size: S, M, L, XL
SKS plastic, rear
Size: S, M, L, XL
SKS plastic, front
Weight
Weight
M - 17.20 kg / 37.92 lbs
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
